Ecco 2.56kWh Lithium Power Battery – 25.6V 100Ah Wall-Mount Energy Storage Solution

The Ecco ELV24100 lithium power battery is a compact, reliable, and efficient residential energy storage solution designed for modern homes and small commercial applications. With advanced LiFePO₄ technology, this power battery delivers long cycle life, enhanced safety, and dependable backup power in a space-saving wall-mounted design.

Whether you are building a modular solar system or upgrading an existing backup solution, this power battery offers performance, scalability, and peace of mind.

Compact & Reliable Power Battery for Home Energy Storage

The Ecco ELV24100 is a 25.6V 100Ah lithium power battery with a total usable energy capacity of 2.56kWh, making it ideal for low-voltage hybrid inverter systems. Its compact form factor allows for easy wall installation, saving valuable indoor space while maintaining high power output.

Designed for everyday energy independence, this power battery is perfect for load shedding backup, solar self-consumption, and small commercial power support.

Advanced BMS for Safe Power Battery Performance

Each Ecco power battery is equipped with an intelligent Battery Management System (BMS) that ensures optimal performance and long service life.

Smart BMS Capabilities:

• Real-time monitoring of voltage, current, and temperature

• Automatic cell balancing to extend power battery lifespan

• Protection against over-charge, over-discharge, over-current, and overheating

• Stable charging and discharging control for system safety

This advanced BMS ensures that your power battery operates efficiently under varying load and environmental conditions.

Scalable Power Battery System – Parallel Ready

The Ecco ELV24100 power battery supports parallel expansion, allowing you to grow your energy storage as your power needs increase.

• Parallel connection of up to 15 lithium power batteries

• Recommended minimum of two batteries for systems above 5kW

• Master-slave communication ensures synchronized and safe operation

This scalability makes the power battery a future-proof investment for expanding solar or backup systems.

Durable, Wall-Mounted Power Battery Design

Designed for indoor use, this power battery features a robust IP20 enclosure and a clean, modern appearance.

• Wall-mount design reduces floor space usage

• Strong metal casing for long-term durability

• Supplied with wall bracket, cables, and inspection report

The compact and lightweight build makes installation simple while maintaining professional-grade reliability.

Technical Specifications

Specifications:

• Battery Type: LiFePO₄ Lithium Power Battery

• Nominal Voltage: 25.6V

• Nominal Capacity: 100Ah

• Total Energy: 2.56kWh

• Charge Voltage: 28.08V

• Discharge Cut-Off Voltage: 22.8V

• Continuous Charge Current: 50A

• Continuous Discharge Current: 100A

• Peak Current: 200A (3ms)

• Dimensions: 403 × 396 × 145 mm

• Weight: 26.68 kg

• Protection Rating: IP20

• Charging Temperature: 0°C to 45°C

• Discharging Temperature: -20°C to 60°C

Key Features

• High-efficiency LiFePO₄ lithium power battery technology

• Intelligent BMS for maximum safety and lifespan

• Wall-mounted, compact, and space-saving design

• Parallel expansion capability up to 15 units

• Stable performance for solar and backup applications

Key Benefits of Using

• Longer lifespan compared to lead-acid batteries

• Faster charging and higher usable capacity

• Low maintenance and high energy efficiency

• Reliable power during outages and load shedding

• Safe and environmentally friendly lithium power battery chemistry

Why Choose Ehumu for Your Power Battery?

Ehumu delivers trusted energy solutions backed by quality products and professional support. When you choose Ehumu, you benefit from:

• Premium-grade lithium power battery solutions

• Compliance with SANS 10142 installation standards

• 5-year limited warranty for peace of mind

• Expert guidance and support for residential and commercial systems

Every power battery supplied by Ehumu is designed to deliver performance, safety, and long-term value.

Warranty & Installation Requirements

• 5-Year Limited Warranty Included

• Installation must be completed by a qualified wireman or registered Master Electrician

• A valid Certificate of Compliance (COC) is required

• Installation photos and proof of professional installation are mandatory for warranty claims

Failure to meet installation requirements may result in warranty rejection.
