Sunsynk 5.5KVA MPPT Hybrid Inverter with Dual Dyness 5.12kWh Lithium Batteries (BX51100)

Sunsynk 5.5KVA MPPT Hybrid Inverter with Dual Dyness 5.12kWh Lithium Batteries (BX51100)

Description:

Dependable Hybrid Solar Power System

A powerful energy storage system made for home and business use is the Dyness 5. 12kWh Lithium Battery & Sunsynk 5. 5KW Hybrid Inverter combination. This kit helps you get the most out of solar energy while lowering your electricity bills with its cutting-edge MPPT solar charging, seamless on- and off-grid functionality, and intelligent power management.

Intelligent and effective, the Sunsynk 5. 5KW Hybrid Inverter

Increased output.

• Lower your electricity cost by increasing your self-consumption rate by as much as 80%.
• Perfectly suited for doubleside PV modular, with a DC/AC ratio of up to 1. 3.
• The highest efficiency of the two MPPT designs is 97. 6%.

Simple to use.

• simple to use with LCD touchscreen and buttons.
• Lead acid battery and lithium ion battery compatible.
• Mobile app and web browser monitoring are both supported.

Dependable.

• PV lighting protection, anti-islanding protection, leakage current protection, and other measures
• Make sure the system operates within 724 hours and provide backup energy from DG for the business as necessary.
• The degree of IP65 protection allows for both indoor and outdoor usage.
• Within 5 milliseconds, it automatically switches between ongrid and offgrid mode.
• The quick reaction in zero export mode within 200 milliseconds, as well as the lack of an export function.

Clever.

• Schedule for charging and discharging that may be programmed.
• Both solar panels and wind turbines may be connected as DC input power.
• A maximum of 16 units can be connected in parallel to increase the overall power of the system.
• adding an energy storage system to the current solar system.

Information from Battery Inputs

• Lead acid or lithium ion batteries are the two types of batteries.
• The Range of Battery Voltage (V): 4060V
• Maximum Charging Current (A): 120 A
• Maximum Discharge Current (A): 120 A
• Charging curve: 3 Steps/Equalization
• External Temperature Sensor: Optional
• Lithium Battery Charging Strategy: Adapting to BMS Automatically

Data for PV String Input

• Max. DC Input Power (W): 6500W.
• 370 V is the PV input voltage (100 V–500 V).
• 125–425 V is the range of MPPT (V).
• Voltage at Startup (V): 150 V.
• PV Input Current (A): 11 A + 11 A.
• Number of MPPT Trackers: 2
• Number of strings per MPPT tracker: 1+1.

Data on AC Output

• Rated AC Output and UPS Power (W): 5000W
• Maximum AC Output Power (W): 5500W
• Peak Power (offgrid): Twice the rated power, 10 seconds.
• Rated AC output current (A): 21. 7. 4 A
• The maximum AC current (in amperes): 25A
• Max Continuous AC Passthrough (A): 35 A.
• Voltage and Output Frequency: 240Vac at 50Hz,
• THD<3% (Linear load<1. 5%) is the grid type.
• THD, the existing harmonic distortion, is less than 3% (Linear load is less than 1. 5%).

Effectiveness

• Maximum efficiency: 97. 60%
• Euro Efficiency: 96. 50%
• Efficiency of MPPT: 99. 90%

Safeguarding

• Integrated PV Arc Fault Detection (Except European Type)
• Integrated PV Input Lightning Protection
• Integrated Anti-Islanding Protection
• Reverse Polarity Protection for PV String Inputs: Integrated
• Integrated Insulation Resistor Detection
• Integrated Residual Current Monitoring Device
• Integrated Output Over Current Protection
• Output Shorted Protection: Integrated
• Integrated Overvoltage Protection for Output

Criteria and Certification

• Regulatory grid: UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IE61727
• IEC621091, IEC621092 are the safety regulations.
• FCC 15 class B, EN6100061, and EN6100063 are the EMC standards.

General Information

• Operating Temperature Range ( C ): 25–60 C , >45 C Derating
• Cooling: Fan
• (dB) Noise: 30
• RS485; CAN is used to communicate with the BMS.
• Weight (kg): 20. 5
• Measurements (mm): 580 mm by 330 mm by 208 mm
• IP65 is the degree of protection.
• Installation Method: Wall-mounted
• Warranty: Five Years

Dyness 5. 12kWh 48V (BX51100) Lithium Battery - High Performance & Long Lasting

A dependable and scalable lithium battery for storing solar energy

The Dyness BX51100 5. 12kWh lithium battery is a high-performance energy storage device intended for solar installations in residential and commercial settings. It is built with LiFePO4 (LFP) technology, which ensures greater efficiency, safety, and longevity. For increasing energy storage demands, the battery supports parallel configurations of up to 40 modules, making it a scalable system.

Important Features:

• Energy Storage with High Capacity
• 5. 12 kWh battery module for a high level of energy backup
• A 51. 2V DC system with a capacity of 100 Ah.
• At 50A (75A max), it supports continuous charge and discharge.

Cutting-edge Lithium Iron Phosphate (LFP) technology

• Enhanced thermal stability and prolonged battery life
• With built-in protection features, it operates safely and reliably.

Intelligent Energy Management and Connectivity

• System monitoring is supported by RS485 and CAN communication.
• Suitable for rack-mounted and wall-mounted setups

A Flexible System for Meeting High Energy Needs

• A maximum of forty battery modules can be connected in parallel.
• adaptable system architecture for business and domestic environments

Perfect Uses

• Backup power systems for homes and businesses.
• Protection from load shedding to ensure continuous power supply.
• Hybrid solar systems that are grid-tied and off-grid.
• Renewable energy storage for homes and businesses.

Installation Requirements and Warranty

• The Dyness battery is covered by a 10-year warranty, while the Sunsynk inverter has a 10-year warranty.
• The installation must be completed by a trained electrician in accordance with SANS 10142.
• A Certificate of Compliance (COC) is necessary to confirm the warranty.
• There may be no coverage for warranty claims if the installation is not adequately documented.
